DERAY-ZoH 125

Zero Halogen & Low smoke heat shrink tubing. The product complies with the stringent requirements of the European rail norm EN45545-2 and the HL3 R22/R23 classification and even over exceeds those. The material is suitable for use in all classes required for the construction of locomotives and rolling stock. It is also suitable for use in underground environments as well as marine, military and aerospace applications.


FEATURES AND BENEFITS

• Low smoke generation - excellent fire safety characteristics
• Emissions of toxic fumes are well below the levels required to meet the relevant standards
• Flexible
• Flame retardant
• Good fluid resistance
• Shrink ratio: 2:1
• Continuous operating temperature: -40°C to 125°C
• Shrink temperature: 120°C min.


TYPICAL APPLICATIONS

• Insulation of electrical components in mass transit applications
• Mechanical and environmental protection in the marine, military, aerospace and heavy industry
• General fire safety applications where there is a risk to people or equipment
 DERAY-ZOH 125(982,1 KB)
